Wireless portal authentication prompts insecure connection

Typical Networking for Portal Authentication

The site is deployed in the wireless Portal networking mode, and adopts the certificate server method for authentication. After the network is set up, it is found that after importing the certificate CA file on some client computers, use the default browser, or the MAC computer firefox device to access the network, the computer will prompt Insecure connection, there is a security access risk!

Check configuration:

2-2  Import certificate

[AP21-LIB-2FWLC]pki domain importdomain

[AP21-LIB-2FWLC-pki-domain-importdomain]undo crl check enable

[AP21-LIB-2FWLC-pki-domain-importdomain]public-key rsa signature name sign encryption name encr

[AP21-LIB-2FWLC-pki-domain-importdomain] quit

[AP21-LIB-2FWLC]pki import domain importdomain pem ca filename root_ca.cer

[AP21-LIB-2FWLC]pki import domain importdomain pem local filename ap21-lib2fwlc.sp.toyaku.ac.jpv2.cer

2-3   Apply server certificate to HTTPS pages

[AP21-LIB-2FWLC] ssl server-policy myssl

[AP21-LIB-2FWLC-ssl-server-policy-myssl] pki-domain importdomain

[AP21-LIB-2FWLC-ssl-server-policy-myssl] quit

[AP21-LIB-2FWLC] undo ip https enable

[AP21-LIB-2FWLC] undo ip http enable

[AP21-LIB-2FWLC] ip https ssl-server-policy myssl

[AP21-LIB-2FWLC] ip https enable

[AP21-LIB-2FWLC] ip http enable

[AP21-LIB-2FWLC] undo portal local-web-server

[AP21-LIB-2FWLC] portal local-web-server https ssl-server-policy myssl tcp-port 2331

[AP21-LIB-2FWLC-portal local-web-server] default-logon-page toyakulogin.zip

[AP21-LIB-2FWLC-portal local-web-server] tcp-port 2331

[AP21-LIB-2FWLC-portal local-web-server] quit

Through wireshark capture, we can see that the client does not receive the intermediate certificate file, so the computer prompts an insecure connection.

Use the certificate-chain-sending enable command to configure the SSL server to send the complete certificate chain during SSL negotiation.

By default, during SSL negotiation, the SSL server only sends the local certificate and does not send the certificate chain.
