★ IPSEC tunnel establishment fails, debug shows IPSEC/7/EVENT:Failed to match profile problem handling experience cases

In the figure below, RUT145167014#2 on the left and 830 (RUT145128081-01) marked yellow on the right establish IPsec.

Customers reported that the IPSEC tunnel establishment failed, with the following debug:

*Nov 12 17:29:40:220 2023 RUT145167014-02 IPSEC/7/EVENT:Failed to match profile: IKE profile was A while IPsec used profile B.

1. According to the debug ipsec error and debug ipsec event information reported on site, the following IPSEC event logs were found:

*Nov 12 17:29:40:220 2023 RUT145167014-02 IPSEC/7/EVENT:

 Could not find tunnel, ike profile name is A.

*Nov 12 17:29:40:220 2023 RUT145167014-02 IPSEC/7/EVENT:

Failed to match flow: ACL not match.

*Nov 12 17:29:40:220 2023 RUT145167014-02 IPSEC/7/EVENT:

Failed to match profile: IKE profile was A while IPsec used profile B.

2. Check the customer"s ipsec configuration and find that the match remote address set by ike profile A is a 24-bit mask, and the address 1.1.1.16 has the smallest value, so when both ends negotiate ike sa, the ike profile A will be matched first. Because the wrong ike profile A is matched when establishing ike sa with 1.1.1.38, which is inconsistent with the ike-profile B called in the ipsec policy, the ipsec tunnel cannot be established.

MSR830 configuration:

#

ipsec policy use2 10 isakmp

 transform-set tran1

 security acl 3100

 remote-address 1.1.1.1

 ike-profile profile2

#

ike profile profile2

 keychain keychain2

 local-identity address 1.1.1.38

 match remote identity address 1.1.1.1 255.255.255.0

 proposal 1

#

MSR3610 configuration:

#

ipsec policy use213 3516 isakmp

 transform-set 1

 security acl name A_IPSEC

 remote-address 1.1.1.16

 ike-profile A

#

ipsec policy use213 3538 isakmp

 transform-set 1

 security acl name B_IPSEC A

 remote-address 1.1.1.38

 ike-profile B

#

ike profile A

keychain A

local-identity address 1.1.1.1

match remote identity address 1.1.1.16 255.255.255.0

proposal 1

#

ike profile B

keychain B

local-identity address 1.1.1.1

match remote identity address 1.1.1.38 255.255.255.0

proposal 1

#

It is recommended to set a more precise mask when configuring match remote to avoid inclusion with other ike profile addresses. The problem was solved after the customer changed the mask to 32 bits.
